This is the complete, generated reference for the Bitbybit 3D CAD platform - every class,
method, input type and enum in the published @bitbybit-dev/* npm packages, produced by TypeDoc
directly from the shipped type declarations, so it never drifts from the code you install.
Roughly 1,400 algorithms are documented here, spanning four geometry kernels and three rendering engines. Use this site when you need the exact signature, parameter DTO or return type of a call. For task-oriented walkthroughs, worked examples and conceptual explanation, use learn.bitbybit.dev instead.
| I want to... | Go to |
|---|---|
| Browse every symbol in one place | Full symbol index |
| Do solid modelling - booleans, fillets, lofts, sweeps, STEP/IGES | OCCT |
| Do fast mesh booleans on manifold geometry | Manifold |
| Do script-driven constructive solid geometry | JSCAD |
| Work with NURBS curves and surfaces | Verb input types |
| Render results in BabylonJS | Babylon |
| Draw any geometry into a scene | Draw |
| Use vectors, matrices, lists and math helpers | Vector, Math, Lists |
| Load models, textures and files | Asset |
| See how the types relate | Type hierarchy |
Everything lives under the root Bit namespace, split into three kinds of entry:
OCCT, JSCAD, Manifold, Vector, Draw, Babylon and their
sub-classes. These carry the methods you call. A class such as OCCTShapes groups the
constructors for a shape family; OCCTBooleans groups union, difference and intersection.Bit.Inputs.*, one namespace per kernel
(OCCT,
JSCAD,
Manifold,
Verb,
Base). Almost every method takes a single
DTO argument rather than a positional parameter list, so the DTO page is where the defaults and
units live. Kernels deliberately repeat names - there is a CircleDto in each - so read the
namespace in the page title to be sure which one you are looking at.Bit.Models.*, the shapes returned to you, plus the enumerations
used by the DTOs.npm install @bitbybit-dev/occt @bitbybit-dev/occt-worker
The kernels are independent of any renderer and run in both Node.js and the browser. Pick the
-worker variant in a browser app to keep the WASM kernel off the main thread. The scaffolding CLI
sets up a working project in one command:
npx @bitbybit-dev/create-app my-project --engine threejs
